Type Type Digital single-lens non-reflex AF/AE camera Recording Media SD/SDHC/SDXC memory cards • SD card speed class-compatible. • UHS-I and II supported. • Use of UHS-II microSDHC/SDXC cards with a microSD to SD adapter is not recommended. When using UHS-II supported cards, use SDHC/SDXC cards compatible with UHS-II. • Eye-Fi cards not supported. • Multimedia cards (MMC) cannot be used. Image Format Approx. 35.9 x 24.0mm Compatible Lenses Canon RF lens group (excluding EF, EF-S and EF-M lenses) When using Mount Adapter EF-EOS R: Canon EF or EF-S lenses (excluding EF-M lenses) Lens Mount Canon RF mount Image Sensor Type CMOS sensor (compatible with Dual Pixel CMOS AF) Effective Pixels Approx. 26.2 megapixels Pixel Unit Approx. 5.76 µm square Total Pixels Approx. 27.1 megapixels Aspect Ratio 3:2 (Horizontal: Vertical) Color Filter System RGB primary color filters Low Pass Filter Installed in front of the image sensor, non-detachable Dust Deletion Feature (1) Self Cleaning Sensor Unit • Removes dust adhering to the low-pass filter. • At power off only / Enable / Disable. Performed automatically (taking about 3.3 sec. as indicated on the screen) or manually (taking about 12.2 sec. as indicated on the screen). • After manually activated cleaning, the camera will automatically restart (Power OFF to ON). • When [Multi Shot Noise Reduction], [Multiple exposures], or [HDR mode] is set, [Clean now] and [Clean manually] cannot be selected. (2) Dust Delete Data acquisition and appending • The coordinates of the dust adhering to the low-pass filter are detected by a test shot and appended to subsequent images. • The dust coordinate data appended to the image is used by the provided software to automatically erase the dust spots. • Not available with EF-S lenses, in cropped shooting or when distortion correction is applied. (3) Manual cleaning (by hand) 2 Recording System Recording Format Compliant to Design rule for Camera File system 2.0 and Exif 2.3. Supports time difference information in Exif 2.31. Image Format JPEG, RAW (CR3, 14 bit RAW format), C-RAW (Canon original) File Size 3:2 Aspect Ratio Large/RAW/C-RAW: 6240 x 4160 Medium: 4160 x 2768 Small 1: 3120 x 2080 Small 2: 2400 x 1600 1.6x (Crop) Large/RAW/C-RAW: 3888 x 2592 Small 2: 2400 x 1600 4:3 Aspect Ratio* Large/RAW/C-RAW: 5536 x 4160 Medium: 3680 x 2768 Small 1: 2768 x 2080* Small 2: 2112 x 1600* 16:9 Aspect Ratio* Large/RAW/C-RAW: 6240 x 3504 Medium: 4160 x 2336 Small 1: 3120 x 1752 Small 2: 2400 x 1344 1:1 Aspect Ratio Large/RAW/C-RAW: 4160 x 4160 Medium: 2768 x 2768 Small 1: 2080 x 2080 Small 2: 1600 x 1600 • Values for Recording Pixels are rounded to the nearest 100,000 or 10,000. • For RAW and JPEG images, information outside the cropping area is not retained. • JPEG images are generated in the set aspect ratio. • RAW images are generated in [3:2], and the set aspect ratio is appended. * Indicate an inexact proportion. File Numbering The following file numbers can be set: 1. File numbering methods a. Continuous numbering i. The numbering of captured images continues even after you replace the card. b. Auto reset i. When you replace the card, the numbering will be reset to start from 0001. If the new SD card already contains images, the numbering will continue from the last recorded image in the card. 2. Manual reset a. Resets the file number to 0001, and creates a new folder 3 Picture Style (1) Auto (2) Standard (3) Portrait (4) Landscape (5) Fine Detail (6) Neutral (7) Faithful (8) Monochrome (9) User Defined 1–3 • In Scene Intelligent Auto, [Auto] will be set automatically. • [Standard] is the default setting for [User Def. 1–3]. White Balance Settings (1) Auto (Ambience priority/White priority) (2) Daylight (3) Shade (4) Cloudy* (5) Tungsten light (6) White fluorescent light (7) Flash (8) Custom (Custom WB) (9) Color temperature * Effective also in twilight and sunset. Auto White Balance Option between ambience priority and white priority settings. Color Temperature Compensation Blue/amber bias: ±9 levels Magenta/green bias: ±9 levels Corrected in reference to the current WB mode’s color temperature. Viewfinder Type OLED color electronic viewfinder Coverage Approx. 100% vertically and horizontally relative to the shooting image area (with image quality L, at approx. 22mm eyepoint). Image Quality Recording Pixels Still photo cropping / Aspect ratio 3:2 16:9 (Crop) 1:1 4:3 16:9 L/RAW/C-RAW Approx. 26.0 megapixels (6240x4160) Approx. 10.1 megapixels (3888x2592) Approx.17.3 megapixels (4160x4160) Approx. 23.0 megapixels (5536x4160) Approx. 21.9 megapixels (6240x3504) M Approx. 11.5 megapixels (4160x2768) Approx. 7.7 megapixels (2768x2768) Approx. 10.2 megapixels (3680x2768) Approx. 9.7 megapixels (4160x2336) S1 Approx. 6.5 megapixels (3120x2080) Approx. 4.3 megapixels (2080x2080) Approx. 5.8 megapixels (2768x2080) Approx. 5.5 megapixels (3120x1752) S2 Approx. 3.8 megapixels (2400x1600) Approx. 3.8 megapixels (2400x1600) Approx. 2.6 megapixels (1600x1600) Approx. 3.4 megapixels (2112x1600) Approx. 3.2 megapixels (2400x1344) * Values for Recording Pixels are rounded to the nearset 100,000th or 10,000th. * For RAW and JPEG images, information outside the cropping area is not retained. * JPEG images are generated in the set aspect ratio. * RAW images are generated in [3:2], and the set aspect ratio is appended. * Colored cells indicate an inexact proportion. Magnification Approx. 0.70 (with 50mm lens at infinity, -1 m-1) Eye Point Approx. 22mm (at -1 m-1 from the eyepiece lens end) 4 Dioptric Adjustment Range Approx. -4.0 to +1.0 m-1 (dpt) Viewfinder Information (1) Movie recording time (2) Maximum burst (3) Possible shots/Sec. until self-timer shoots (4) Focus Bracketing/ Multiple-exposure/HDR shooting/Multi Shot Noise Reduction/Bulb time/Interval timer (5) Touch Shutter (6) AF method (7) AF operation (8) Drive mode (9) Metering mode (10) Anti-flicker shooting (11) Shooting mode/Scene icon (12) AE lock (13) Flash-ready/FE lock/High-speed sync (14) Shutter speed/Multi-function lock warning (15) Aperture (16) AF point (1-point AF (17) Exposure level indicator (18) Exposure compensation (19) Highlight tone priority (20) ISO speed (21) Create folder (22) Movie recording size (23) No. of shots left for focus bracketing/multiple exposures/interval timer (24)Temperature warning (25) Battery level (26) Exposure simulation (27) AEB/FEB (28) Magnify button (29) Still photo cropping (30) Aspect ratio (31) Auto Lighting Optimizer (32) Picture Style (33) White balance/White balance correction (34) Quick Control button (35) Image Quality (36) Bluetooth®/Wi-Fi® function (37) Wi-Fi® signal strength (38) Histogram (39) Electronic level (40) GPS acquisition status (41) Flash exposure compensation (42) Focus distance display Autofocus Type Phase-difference detection system with image sensor (Dual Pixel CMOS AF) AF Points Max. 4,779 When selected with cross keys. AF Working Range EV -5 to 18 (f/1.2, at 73°F/23°C, ISO 100, One-Shot AF) Focusing Modes (1) One-Shot AF (2) Servo AF (3) Manual (Manual focus) 5 AF Point Selection and AF Operation AF Method AF Point Selection AF Operation Face+Tracking AF Automatic selection (auto detection), or AF points can be set manually and freely in the AF area. AF prioritizing subjects targeted by Face+Tracking. If no Face+Tracking subject is detected, the entire AF area is used for auto selection AF. Spot AF* Autofocuses targeting any specified AF points. (In an area 50% of the size of a 1-point AFzone.) AF targeting specified AF points. (If there are faces in the area, they take precedence.) 1-point AF AF points can be set manually and freely in the AF area. AF targeting specified AF points. (If there are faces in the area, they take precedence.) Expand AF Area (Above, below, left and right/Around) AF points can be set manually and freely in the AF area. AF prioritizing specified AF points, supplemented by AF points above, below, left and right or around in the expansion area. (If there are faces in the area, they take precedence.) Zone AF* Zones covering specific areas can be set manually and freely in the AF area. Automatic AF point selection in the specified zone. (Prioritizes subjects at close range, but any faces in the area take precedence.) • AF points can be moved by touching the screen or using the Main Dial, Quick Control Dial or cross keys. • *Not available in 4K movie recording. AF Assist Beam (1) Enable (2) Disable (3) LED AF assist beam only • Focus range with the AF-assist beam is generally no more than 11.5 ft. / 3.5 m (at f/5.6). • Options restricted to [Enable] / [Disable in Basic Zone modes. • [AF- assist beam firing] is set to [Disable] in Landscape, Panning, Kids, and Sports modes. Exposure Control Metering Modes Real-time metering with image sensor (384 [24x16]) (1) Evaluative metering (AF point-linked) (2) Partial metering (approx. 5.5% of the area at the center of the screen) (3) Spot metering (approx. 2.7% of the area at the center of the screen) • AF point-linked spot metering not provided. (4) Center-weighted average metering Metering Range EV -3 – 20 (at 73°F/23°C, ISO 100) (Still Photo Shooting) Exposure Control Systems (1) Scene Intelligent Auto (2) Flexible-priority AE (Fv) (3) Program AE (P) (4) Shutter-priority AE (Safety shift possible) (Tv) (5) Aperture-priority AE (Safety shift possible) (Av) (6) Manual exposure (M) (7) Bulb (8) Custom shooting mode C1, C2, C3 6 ISO Speed Range Manual Normal ISO 100 to 40000 (in 1/3-stop or whole-stop increments) Expanded L: equivalent to ISO 50, H1: 51200, H2: 102400 • For [Highlight tone priority], the settable ISO speed range will be ISO 200 to 40000. • ISO speed safety shift possible with Custom Function. • All the expanded ISO speeds, even for movies, are only “equivalent speeds.” Auto Shooting Mode ISO Settings No Flash With Flash Scene Intelligent Auto ISO 100–12800 ISO 100–1600 Fv/P/Tv/Av/M ISO 100–40000*1 ISO 100–1600*1 Silent Mode ISO 100-12800 -(Except with AF-assist beam) B ISO 400 fixed*1 *2 ISO 400 fixed * 1 It depends on [Minimum] and [Maximum] of [ISO speed settings][Range for stills]. * 2 If outside the range set for ISO Auto, the value nearset ISO 400 is used.. Exposure Compensation Manual ±3 stops in 1/3- or 1/2-stop increments AEB ±3 stops in 1/3- or 1/2-stop increments AE Lock (1) Auto AE lock • The metering mode for AE lock after focus can be customized. (2) Manual AE lock • In the Fv, P, Tv, Av and M modes, enabled with the AE lock but 7 Shutter Lag Time With SW-1 ON, time lag between SW-2 ON Drive Mode Silent LV Shooting Release Time Lag Single Shooting No flash Approx. 55 ms Flash Approx. 147 ms Silent Shutter – Approx. 55 ms With the aperture stopped down by 3 stops or less from the open aperture. If the SW-1 and SW-2 are pressed simultaneously, release time lag will be long. The release time lag may become further longer depending on shooting conditions, such as when shooting in a dark environment. External Speedlite Flash Metering E-TTL II auto flash Flash Exposure Compensation ±3 stops in 1/3- or 1/2-stop increments FE Lock Provided External Flash Settings The camera can set the following with EL and EX series Speedlites: (1) External flash control • Flash firing, E-TTL II Flash metering, Slow synchro, Safety FE, Flash mode, Wireless function, Flash zoom, Shutter synchronization and Flash exposure compensation (2) Flash Custom Function setting • The setting options for both (1) and (2) will differ depending on the Speedlite used. Drive System Drive Modes and Continuous Shooting Speed (1) Single shooting (2)High-speed continuous shooting • Max. approx. 5.0 fps ⚪ The conditions are attaining the maximum continuous shooting speed are as follows: ⚪ Shooting with a fully charged battery in One-Shot AF mode at a 1/500 sec. or faster shutter speed and maximum aperture (depending on the lens), at room temperature (73°F/23°C), without flicker reduction, or image stabilization (depending on the lens). ⚪ The continuous shooting speed for high-speed continuous shooting may be lower, depending on conditions such as these: battery level, temperature, flicker reduction, Dual Pixel RAW shooting, shutter speed, aperture, subject conditions, brightness, AF operation, type of lens, use of flash and shooting settings. • With Servo AF: Max. approx. 4.0 fps (shooting speed priority) • When set to reduce flicker: Max. approx. 4.0 fps • In flash photography: Max. approx. 2.3 fps (3) Low-speed continuous shooting (Tracking priority) • Max. approx. 2.6 fps (4) Self-timer: 10 sec./remote control (5) Self-timer: 2 sec./remote control (6) Self-timer: Continuous Shooting 8 Maximum Burst Image Quality Image File Size (approx. MB) Possible Shots (approx.) Maximum Burst (approx.) Standard High-speed (UHS-II) Large (Fine) 9.1 3320 Full Full Large (Normal) 4.9 6060 Full Full Medium (Fine) 5.1 5820 Full Full Medium (Normal) 2.9 10280 Full Full Small 1 (Fine) 3.4 8750 Full Full Small 1 (Normal) 2.0 14620 Full Full Small 2 1.9 15760 Full Full RAW 29.1 1040 50 Full C-RAW 17.1 1780 130 Full RAW + Large (Fine) 29.1 + 9.1 790 42 98 C-RAW + Large (Fine) 17.1 + 9.1 1160 66 170 • The number of possible shots and maximum burst (standard) apply to a 32GB card based on Canon’s testing standards. The maximum burst (High-speed) apply to a 32GB card based on Canon’s testing standards. • The file size, number of possible shots and maximum burst vary depending on shooting conditions (aspect ratio, subject, memory card brand, ISO speed, Picture Style, Custom Function, etc.) • “Full” indicates that shooting is possible until the card becomes full. Live View Functions Shooting Modes Still photo shooting and video shooting Focusing (1) Dual Pixel CMOS AF (2) Contrast AF (When recording 4K movies) (3) Manual focus • Magnified view possible by approx. 5x or 10x for manual focusing (not possible during movie shooting). • With Contrast AF as used when recording 4K movies, focusing may take longer than when recording Full HD or HD movies, and focusing with certain lenses may be difficult. Metering Modes (1) Center-weighted average metering • Metering brightness range: EV -1 – 20 (at 73°F/23°C, ISO 100) (Video) (2) AF point-linked evaluative metering • For face detection with Face detection + Tracking AF. Metering Range EV -2.5 – 18 (f/1.2, center AF point, at 73°F/23°C, ISO 100, One-Shot AF, with 29.97 fps) (When Recording movies) Grid Display (1) 3x3 (2) 6x4 (3) 3x3+diagonals Video Shooting File Format MP4 Video: MPEG-4 AVC / H.264 • Variable (averaged) bit rate* Audio: Linear PCM AAC *For video snapshots and HDR movies are fixed at AAC, and for movie auto exposures and for movie manual exposures, AAC or Linear PCM in [C.Fn III-9] is selectable. 9 Video Recording Size and Frame Rates Movie-recording Quality 4K (UHD) 3840 X 2160 23.98 fps IPB Full HD 1920 x 1080 59.94 fps IPB 29.97 fps IPB IPB (Light) HD 1280 x 720 59.94 fps IPB 29.97 fps IPB • Full HD not available with EF-S lenses or with moving cropping. • Outputted in 4K (UHD) resolution through image processing. Continuous Shooting Time Video Recording Size Total Recording Time (approx.) Bit Rate/File Size (approx.) 8GB 32GB 128GB 4K (UHD) 3840 x 2160 23.98 fps 25.00 fps IPB 8 min. 35 min. 2 hr.20 min. 120 Mbps 869 MB/min. Full HD 1920 x 1080 59.94 fps 50.00 fps IPB 17 min. 1 hr. 09 min. 4 hr. 37 min. 60 Mbps 440 MB/min. 29.97 fps 25.00 fps HDR Movies IPB 33 min. 2 hr. 15 min. 9 hr. 01 min. 30 Mbps 225 MB/min. 29.97 fps 25.00 fps IPB (Light) 1 hr. 26 min. 5 hr. 47 min. 23 hr. 11 min. 12 Mbps 87 MB/min. HD 1280 x 720 59.94 fps 50.00 fps IPB 38 min. 2 hr. 34 min. 10 hr. 19 min. 26 Mbps 196 MB/min. 29.97 fps 25.00 fps HDR Movies IPB 1 hr. 13 min. 4 hr. 53 min. 19 hr. 34 min. 13 Mbps 103 MB/min. • Bit rate indicates video output only; audio is not included. • Video recording is interrupted if the maximum recording time per video, 29 min. 59 sec., is exceeded. •When movie crop shooting is set to [Disable] or movie digital IS is set to [Disable]. • There is no restriction to automatically stop movie shooting even when the file size reaches 4GB. • Sound is not recorded for approx. the last two frames when the compression method for movie recording quality is IPB or IPB Light (audio: AAC) and [C .Fn III-9: Audio compression] is set to [Enable]). • When you play back movies on Windows, movie images and sound may become slightly out of synchronization. Focusing (1) Dual Pixel CMOS AF (2) Manual focus • Magnified view possible by approx. 5x or 10x for manual focusing (not p 10 Exposure Control Shooting Mode Shutter Speed (sec.) Aperture Auto Manual Auto Manual Movie Auto Exposure Yes — Yes — Movie Manual Exposure — Yes — Yes Shutter Speed Frame Rate Settable Shutter Speeds Movie Auto Exposure Movie Manual Exposure HDR Movie 59.94 fps 1/4000 to 1/60 1/4000 to 1/8 -- 50.00 fps 1/4000 to 1/50 -- 29.97 fps 1/4000 to 1/30 1/4000 to 1/60 25.00 fps 1/4000 to 1/25 1/4000 to 1/50 23.98 fps 1/4000 to 1/25 -- ISO Speed (Recommended Exposure Index) Shooting Mode ISO Speed Full HD / HD 4K Auto Manual Auto Manual Movie Auto Exposure Normal ISO Speed Range 100 to 25600 — 100 to 12800 — Maximum expanded ISO Speed H2 (102400) — H2 (102400) — Movie Manual Exposure Normal ISO Speed Range 100 to 25600 100 to 25600 100 to 12800 100 to 12800 Expanded ISO Speed Range H2 (102400) H2 (102400) H2 (102400) H2 (102400) HDR Movie 100 to 25600 — — — Time-lapse Movie Normal ISO 100 to 25600 100 to 25600 100 to 12800 100 to 12800 • Auto setting of ISO speed ⚪ Even if ISO speed range is altered with [ISO speed settings], the setting is not effective for the normal ISO speed range. ⚪ [ISO speed settings] is effective to set the maximum ISO speed for the ISO expansion. • Manual setting of ISO speed ⚪ Normal ISO speed range and Maximum ISO speed with the ISO expansion can be manually set within the range set with [ISO speed settings]. • Expanded ISO speeds: H1 (ISO 51200 equivalent), H2 (ISO 102400 equivalent). Note that L (ISO 50) cannot be set. • The expanded ISO speeds are only “equivalent” ISO speeds. • For HDR movie shooting, an expanded ISO speed cannot be set. The maximum will be ISO 200. Exposure Compensation ±3 stops in 1/3- or 1/2-stop increments LCD Monitor Type TFT color, liquid-crystal monitor Monitor Size 3.0-inch (screen aspect ratio of 3:2) 2.95 in./7.50cm diagonal (2.46 in./6.24cm width, 1.64 in./4.16cm height) Dots Approx. 1.04 million dots Coverage Approx. 100% vertically/horizontally 11 Brightness Control Manually adjustable to one of seven brightness levels Coating Clear View LCD II • Anti-smudge coating applied. • Anti-reflection coating not applied. Interface Languages 29 (English, German, French, Dutch, Danish, Portuguese, Finnish, Italian, Ukraine, Norwegian, Swedish, Spanish, Greek, Russian, Polish, Czech, Hungarian, Vietnamese, Hindi, Romanian, Turkish, Arabic, Thai, Simplified/Traditional Chinese, Korean, Malay, Indonesian, Japanese) Playback Display Format (1) Single-image display • No information display • Basic information display • Detailed shooting information display ⚪ Detailed information ⚪ Lens/Histogram information ⚪ White balance information ⚪ Picture Style information 1 ⚪ Picture Style information 2 ⚪ Color space/Noise reduction information ⚪ Lens aberration correction information 1 ⚪ Lens aberration correction information 2 ⚪ Record of sent images ⚪ GPS information Display selection is available for Basic information display and Shooting information display. (2) Index display • 4-image index • 9-image index • 36-image index •100-image index Highlight Alert The white areas with no image data will blink. Histogram Brightness and RGB Quick Control Function Function The Quick Control screen is accessed by pressing the Quick Control button during still photo shooting. Image Protection and Erase Protection (1) Single image (select image) (2) Select range (3) All images in a folder (4) All images on card • Image browsing and image search can be based on ratings. • Ratings-based image selections also possible with DPP. (5) All found images (only during image search) Erase Except protected images (1) Select images to erase (2) Select range (3) All images in folder (4) All images on card (5) All found images (only during image search) Direct Printing Compatible Printers Images can be sent via Wi-Fi® to a PictBridge-compatible (Wireless LAN) printer and printed. DPOF: Digital Print Order Format DPOF Compliant to DPOF Version 1.1 12 Wi-Fi® Standards Compliance IEEE 802.11b/g/n Transmission Method DS-SS modulation (IEEE 802.11b) OFDM modulation (IEEE 802.11g/n) Transition Frequency (Central Frequency) Frequency: 2412 to 2462 MHz Channels: 1 to 11 channels Connection Method (1) Camera access point mode (2) Infrastructure mode Security Connection Method Authentication Encryption Encryption Key Format and Length Camera Access Point WPA2-PSK AES • ASCII 8 characters Open Disable Infrastructure Open WEP • Hexadecimal 10 digits • Hexadecimal 26 digits • ASCII 5 characters • ASCII 13 characters Disable Shared key WEP Same as WEP above WPA-PSK TKIP AES • Hexadecimal 64 digits WPA2-PSK • ASCII 8–63 characters Communication with a Smartphone Images can be viewed, controlled, and received using a smartphone. Remote control of the camera using a smartphone is possible depending on the Camera Connect specifications. Images can be sent to a smartphone. Remote Operation Using EOS Utility The camera can be controlled via Wi-Fi® using EOS Utility. Print from Wi-Fi® Printers Images can be sent to a Wi-Fi® printer compliant to PictBridge (wireless LAN). Send Images to a Web Service Still photos (JPEG) and movies (MP4) can be uploaded to a CiG (CANON iMAGE GATEWAY) album. With the CiG service, images can be sent to social media or a photo album link can be sent (by the CiG specifications). A link to a CiG album can be emailed. Bluetooth® Standards Compliance Bluetooth Specification Version 4.1 compliant (Bluetooth low energy technology) Transmission Method GFSK modulation Customization Custom Functions 23 Custom Functions are settable. 13 Custom Controls Customizable Buttons Still Photo Shooting Movie Shooting Shutter button Multi-function button Movie button AF-ON button Multi-function button AE lock button AF-ON button AF point selection button AE lock button Lens AF stop button AF point button Up key (cross keys) Lens AF stop button Left key Up key (cross keys) Right key Left key Down key Right key SET b 14 Battery Battery Pack LP-E17x 1 • With the AC Adapter + DC Coupler, AC power is possible. • With the USB Power Adapter PD-E1, in-camera charging of LP-E17 is possible. The USB Power Adapter PD-E1 is not compatible with powering the camera. Number of Possible Shots (Approx. Shots) Shooting Method Temperature Possible Shots Screen Room Temperature (73°F / 23°C) 250 Low Temperatures (32°F / 0°C) 240 Screen (Eco Mode: On) Room Temperature (73°F / 23°C) 270 Viewfinder (EVF) (Smooth) Room Temperature (73°F / 23°C) 210 Low Temperatures (32°F / 0°C) 200 Viewfinder (EVF) (Power saving) Room Temperature (73°F / 23°C) 250 Low Temperatures (32°F / 0°C) 240 • Based on CIPA testing standards. • Using a fully charged Batter Pack LP-E17 Battery Check Automatic battery check when the power switch is turned ON. Displayed in 4 levels. • Battery level can be checked on the LCD panel and in the viewfinder. •Type of power source used. •Remaing capacity (3 level battery capacity indicator). •Recharge performance. Power Saving Power turns off after the set time of non-operation elapses. Display off Available time options: 15 sec. / 30 sec. / 1 min. / 3 min. / 5 min. / 10 min. / 30 min. Auto power off Available time options: 30 sec. / 1 min. / 3 min. / 5 min. / 10 min. Disable Viewfinder off Available time options: 1 min. / 3 min. / Disable • At least approx. 6 min. until auto power off while the [Date/Time/Zone] screen is displayed. Date/Time Battery Built-in secondary battery When fully-charged, the date/time can be maintained for approx. 3 months • Recharge time: approx. 8 hrs. ⚪ The recharge time required to provide the above number of months with no battery pack installed. Start-up Time Approx. 0.82 sec. • Based on CIPA testing standards. Dimensions and Weight 15 Dimensions (W x H x D) Approx. 5.22 x 3.35 x 2.76 in. / 132.5 x 85.0 x 70.0mm • Based on CIPA standards. (Depth from tip of grip to LCD screen surface: Approx. 2.34 in. / 59.4mm Weight Approx. 1.07 lbs. / 485g (including battery, SD memory card; without body cap) Approx. 1.0 lbs. / 440g (body only; without battery, card or body cap) Operating Environment Working Temperature Range 32–104°F / 0–40°C Working Humidity Range 85% or less
